News

Conical Twin Screw Barrel Size Codes Explained

A conical twin screw code such as 65/132 normally identifies the two nominal screw diameters: 65 mm at the smaller front end and 132 mm at the larger rear end. It does not specify length, spline, center distance, flight geometry or barrel interfaces, so the code alone cannot confirm interchangeabili......

What Is a Conical Twin Screw Barrel?

A conical twin screw barrel has two intermeshing screws whose working diameters increase from the smaller discharge end toward the larger drive end. The matching barrel bores follow that taper. EJS lists nitrided and bimetallic builds for this hardware. Its published data gives a 0.4-0.7 mm nitrided......

Twin screw barrel applications: match the replacement to the process

Twin screw applications fall into different hardware patterns. Compounding, masterbatch and many pelletizing lines often use parallel screws assembled from removable elements with modular barrel sections. PVC pipe, profile and panel lines commonly use counter-rotating conical or parallel systems wit......

Custom twin screw barrel manufacturing: what buyers should approve

Start with an original drawing or a controlled measurement package. Identify which dimensions are nominal and which came from a worn component. Freeze the machine interfaces and application requirements in a manufacturing drawing, then agree on the inspection records before production begins. A samp......

What is a parallel twin screw barrel?

A parallel twin screw barrel contains two screws whose centerlines remain parallel through the process section. The screw outside diameters and center distance do not taper from the drive end to the discharge end. Parallel systems may be co-rotating or counter-rotating, and their process sections ma......

Twin screw barrel problems: what to inspect before replacing parts

Do not order twin screw parts from a torque alarm or worn-looking photograph alone. Preserve the screw element sequence, measure every barrel section by position, inspect the shaft and drive connection, and compare operating data under the same recipe and settings. Use the machine maker's limits for......
