Injection Screw Barrel

Every plastic people knows injection screw barrel is more used than extrusion screw barrels, naturally EJS production can’t show up without injection screw barrel.

Send Inquiry

Product Description

INJECTION SCREW BARREL

With a positive and progressive attitude to customer's satisfaction, our company repeatedly improves our products quality to meet the requirements of OEM machine builders as well as end users. More further EJS focuses on safety, reliability, environmental requirements, and innovation for High Quality China Injection Screw Barrel. Consequently our products are sold not only in the Chinese market, but also welcomed in the international industry.


High Quality China Screw and Barrel, Screw Barrel, Injection Barrel, Injection Molding Screw and Barrel, Whether you have detailed drawings or not, you can talk to our sales person about your sourcing requirements. We've been looking forward to cooperating with friends from all over the world.


E.J.S  uses high quality 1.8509 to produce screws and barrels for customers globally to ensure the quality of screws and barrels, because raw material is the core and footstone.


Every plastic people knows injection screw barrel is more used than extrusion screw barrels, naturally EJS production can’t show up without injection screw barrel.

Customized injection screw barrels are produced every year for Arburg, Negri Bossi, BOY , Haitian injection moulding machines.

We could make new designs as per your formula, capacity and improve on your design. If a trouble shooting is needed. Or increase the machine power by changing the injection screw barrel size.


Bore diameter available for INJECTION SCREW BARREL

¢16~¢220


Popular Materials used for INJECTION SCREW BARREL

38CrMoAlA (DIN1.8509)

34CrAlNi7 (DIN1.8550)

31CrMoV9 (DIN1.8519)

40Cr (AISI 4340)

42CrMo ( AISI4140)

SKD61

SKD61 hardfacing

D2 ( Din1.2379)


Surface Treatment of INJECTION SCREW BARREL

Full body nitrided

Quenching

Bimetallic alloy coating

Different percentage of glass fiber added, different bimetallic type could be chosen


Application of INJECTION SCREW BARREL

Since first injection moulding machine was born in 1920s, injection screw barrel has been closely linked to our life, from private to professional, from down to the earth to the air space, nobody is leading their life without a product made from injection moulding machine, starting from toothbrush to your phone chargers, computer components, stationery, buttons, gears, electric appliances, car components, cosmestic bottles, switches, buckets, basins, trash cans, shoes and a million others.


Inspection of INJECTION SCREW BARREL

Quality is the key, every INJECTION SCREW BARREL is carefully inspected by our inclusive EJS personnel with the Inspection Report well filed for both customer and our internal use.


Can you help me to design a new injection screw barrel, because I want a larger capacity?

Yes, E.J.S could make a new design as per the material you are processing and the product you are producing. If output increase is needed per hour, please provide us critical connecting dimensions and E.J.S will make you a new design accordingly.


About E.J.S.

EJS Screw Barrels is a newly created brand name for Export business with manufacturing experiences since 1992.
A screw barrel manufacturer dedicated on producing customized screw barrel and design extruder screw barrels, injection moulding screw barrels.


Bimetallic Screw Barrels

We started to make bimetallic screw barrel at a very early age, almost the same time as the first bimetallic barrel was born in China. Now we have several types for options depending on different applications

Bimetallic Barrels

Alloy Type

EJS01 Alloy

EJS02 Alloy

EJS03 Alloy

EJS04 Alloy

Alloy Components

Fe+Ni+Cr+B
(Fe:65, Ni:14, Cr8, B:3.5)

Ni+Cr+Co+B

Ni+Cr+Co+V+B

Ni+Wc+Cr+B
(Ni:50, Wc:15~35,Cr:6~8, B:2.5~3.2)

Wearing Resistance

★★★

★★

★★★

★★★★

Corrosion Resistance

★★

★★★

★★★

★★★

Alloy Thickness

2~3mm

1.5~2mm

1.5~2mm

1.5~2mm

Hardness

HRC 58-65

HRC 50-58

HRC 55-60

HRC 55-65

Temperature Range

≤400

≤450

≤450

≤600

Coefficient Thermal

RT~250℃

11.0x10-6

11.0x10-6

11.5x10-6

11.0x10-6

Expansion(/℃)

RT~400℃

11.4x10-6

11.4x10-6

12.4x10-6

12x10-6

Range of Workable Length

700mm~3000mm/piece

Base Steel Vastly Used

40Cr: 42CrMo

Mark in the list: ★★★★ Excellent; ★★★ Very Good; ★★Good


Bimetallic Screws

Suitable for

Single Screw, Twin Parallel Screw, Twin Conical Screw

Alloy Type

Ni60

CoImonoy 56

CoImonoy 83

Alloy Components

Ni+Cr+Fe+Si
(Ni:65, Cr:17, Fe:15, Si:5)

Ni+Cr+Si+Fe
(Ni: 68, Cr:18, Si:5, Fe:5)

Ni+Wc+Cr+C
(Ni:40, Wc:34, Cr:20, C:2)

Anti-Wearing Level

★★★

★★★

★★★★

Anti-Corrosion Level

★★★★

★★★★

★★★★

Alloy Thickness

1~1.5mm

1~1.5mm

1~1.5mm

Hardness

HRC 56-62

HRC 46~61

HRC 43-48

Applied Glass Fiber

Under 10%





Range of Workable Length

Any length needed

Base Steel Vastly Used

38CrMoAI(1.8509), 34CrAINi7(1.8550), 31CrMoV9(1.8519)

Mark in the list: ★★★★ Excellent; ★★★ Very Good; ★★Good



Quality Inspection

Quality is a very important step during production. For making a quality screw barrel, all tolerances should be fulfilled and all dimensions should be correct and put in records.

We provide inspection report, material certificate for every of our supplied screw barrels.


Packaging

Packaging is the last but very important step before shipping. A strong and smart packing box is also part of our quality. It is not only used to protect the screws barrels well during transportation, also provide an easy way for our customer to unpack.
