Home > Products > Extruder Screw Barrel > Extruder Screw Barrel
Extruder Screw Barrel
  • Extruder Screw BarrelExtruder Screw Barrel
  • Extruder Screw BarrelExtruder Screw Barrel
  • Extruder Screw BarrelExtruder Screw Barrel
  • Extruder Screw BarrelExtruder Screw Barrel
  • Extruder Screw BarrelExtruder Screw Barrel
  • Extruder Screw BarrelExtruder Screw Barrel

Extruder Screw Barrel

EJS is a well known manufacturer for extruder screw barrel, especially conical screw barrel, parallel twin screw barrel, single screw extruder screw and barrel, rubber extruder screw barrel.

Send Inquiry

Product Description

Extruder Screw Barrel

EJS is a well known manufacturer for extruder screw barrel, especially conical screw barrel, parallel twin screw barrel, single screw extruder screw and barrel, rubber extruder screw barrel.



From establishment till today, extruder screw barrel has always been our hottest products.

We produce most conical screw barrels.

We export most of single screw barrels.



Our most customers are staying with us from first cooperation, their orders grow from small to big, and their order are becoming more often. Because of this, our factory grows in all these years, now we have 400 full time workers, over 20 workshops at 4000m² of working area.

Another big difference is about the lead-time. When more orders are granted by our customers, longer lead-time is expected. We appreciate that most of the time, customers will choose to wait, because they are very clear that quality always comes first, haste doesn’t make any good jobs.



For a lot of times, order quantity of Extruder screw barrel is not big, especially comparing to injection molding machine screw barrel. We are happy that we have nice orders like 80 sets, 300 sets once in a while, which is always welcome by our workers, as they can keep machine set-up longer.


About E.J.S.

EJS Screw Barrels is a newly created brand name for Export business with manufacturing experiences since 1992.
A screw barrel manufacturer dedicated on producing customized screw barrel and design extruder screw barrels, injection moulding screw barrels.


Bimetallic Screw Barrels

We started to make bimetallic screw barrel at a very early age, almost the same time as the first bimetallic barrel was born in China. Now we have several types for options depending on different applications

Bimetallic Barrels

Alloy Type

EJS01 Alloy

EJS02 Alloy

EJS03 Alloy

EJS04 Alloy

Alloy Components

Fe+Ni+Cr+B
(Fe:65, Ni:14, Cr8, B:3.5)

Ni+Cr+Co+B

Ni+Cr+Co+V+B

Ni+Wc+Cr+B
(Ni:50, Wc:15~35,Cr:6~8, B:2.5~3.2)

Wearing Resistance

★★★

★★

★★★

★★★★

Corrosion Resistance

★★

★★★

★★★

★★★

Alloy Thickness

2~3mm

1.5~2mm

1.5~2mm

1.5~2mm

Hardness

HRC 58-65

HRC 50-58

HRC 55-60

HRC 55-65

Temperature Range

≤400

≤450

≤450

≤600

Coefficient Thermal

RT~250℃

11.0x10-6

11.0x10-6

11.5x10-6

11.0x10-6

Expansion(/℃)

RT~400℃

11.4x10-6

11.4x10-6

12.4x10-6

12x10-6

Range of Workable Length

700mm~3000mm/piece

Base Steel Vastly Used

40Cr: 42CrMo

Mark in the list: ★★★★ Excellent; ★★★ Very Good; ★★Good


Bimetallic Screws

Suitable for

Single Screw, Twin Parallel Screw, Twin Conical Screw

Alloy Type

Ni60

CoImonoy 56

CoImonoy 83

Alloy Components

Ni+Cr+Fe+Si
(Ni:65, Cr:17, Fe:15, Si:5)

Ni+Cr+Si+Fe
(Ni: 68, Cr:18, Si:5, Fe:5)

Ni+Wc+Cr+C
(Ni:40, Wc:34, Cr:20, C:2)

Anti-Wearing Level

★★★

★★★

★★★★

Anti-Corrosion Level

★★★★

★★★★

★★★★

Alloy Thickness

1~1.5mm

1~1.5mm

1~1.5mm

Hardness

HRC 56-62

HRC 46~61

HRC 43-48

Applied Glass Fiber

Under 10%





Range of Workable Length

Any length needed

Base Steel Vastly Used

38CrMoAI(1.8509), 34CrAINi7(1.8550), 31CrMoV9(1.8519)

Mark in the list: ★★★★ Excellent; ★★★ Very Good; ★★Good



Quality Inspection

Quality is a very important step during production. For making a quality screw barrel, all tolerances should be fulfilled and all dimensions should be correct and put in records.

We provide inspection report, material certificate for every of our supplied screw barrels.


Packaging

Packaging is the last but very important step before shipping. A strong and smart packing box is also part of our quality. It is not only used to protect the screws barrels well during transportation, also provide an easy way for our customer to unpack.
